Scan mode:
1. Linear scanning distribution
Scanning measurement range: (10Hz) - (10MHz) 40000 scanning point, resolution 0.25kHz, 0.5kHz and 1kHz.
2. Segment frequency scanning measurement distribution
Frequency scanning measurement range: (0.5kHz) - (1MHz), 2000 scanning points; (0.5kHz) - (10kHz) (10kHz) - (100kHz) (100kHz) - (500kHz) (500kHz) - (1000kHz)
Other technical parameters:
Amplitude measurement range: (-120dB) to (+20 dB)
Amplitude measurement accuracy: 0.1dB
Scanning frequency accuracy: 0.01%
Signal input impedance: 1MΩ
Signal output impedance: 50Ω
Signal output amplitude: ± 20V
In-phase test repetition rate: 99.9%
Measuring instruments dimensions (L*W*H): 300*340*120 (mm)
Instrument’s aluminum box dimension (L*W*H): 310*400*330 (mm)
Overall weight: 10kg
Working temperature: -10℃~+40℃
Storage temperature: -20℃~+70℃
Relative humidity: <90%, Non-condensing
