Specifications
Rated power (KVA/KW): 6/5.4
Noise level (dBA): < 60
Input specification
Nominal voltage (VAC): 220
Voltage range (VAC): 120-276
Frequency range (Hz):46-54
Number of phases: 1P + 2W + G
Output specification
Voltage (VAC): 220 ±1% VAC
Frequency (Hz): Main mode (46 – 54Hz)/ (56 – 64Hz); Battery mode 50 (± 1%)Hz/ 60 (± 1%)Hz
Switching time (second): 0 second, switch from inverter to bypass in 0 second
Waveform: Standard sine wave
Connection port
Communication port: RS-232
Battery
Quantity and type: 16 x 12V x 7Ah
Power backup time (100% load): 6-10 minutes
Charging time: reaches 90% within 8 hours of charging
Dimension & Weight
Product dimensions (mm): 660 x 360 x 721 (L x W x H)
Weight: 57kg
Operating environment
Operating temperature: 0ºC – 40ºC
Humidity: 20 – 90% without condensation
