IdealTek CCP-220VAC-(N/P)2KW-15KV High Voltage Capacitor Charging DC Power Supply (2KW, 15KV, 133mA)

Input

Voltage: SIngle-phase 220Vac±10%

Frequency: 50Hz/60Hz

Output

Rated power: 2KW

Output voltage: 15KV

Output current: 133mA

Ripple (Vr.m.s.): ≤0.5% rated output

Efficiency: ≥85%

Setting and display

Control mode: DB25 analog port and RS485 communication port

Display mode: 4/1/2 LED digital display

        Display resolution: ≤1%

Protection and monitoring function: Load discharging protection, short circuit protection, over current protection

Noise: ≤55dB

Protection degree: IP20

Cooling method: Forced air cooling

Working conditions: 0°C～40°C, 10%～90% (non-condensing)

Storage conditions: -20°C～60°C, 10%～90%

Size: 483*177*550 (19” 6U)

Weight: ~45kg
