Rated Value:
Voltage: 0~80V
Current: 0~60A
Power: 1000W
Channels: 1CH
CV Mode:
Range: 0~80V
Setting Resolution: 1mV
Setting Accuracy (23±5°C): ≤0.03%+0.02%F.S.
Voltage Ripple(20Hz-20MHz): ≤10mVrms
: ≤50mVp-p
CC Mode:
Range: 0~60A
Setting Resolution: 1mA
Setting Accuracy (23±5°C): ≤0.1%+0.1%F.S.
Current Ripple(20Hz-5MHz): ≤60mArms
CP Mode:
Range: 1000W
Setting Resolution: 0.1W
Setting Accuracy (23±5°C): 0.5%F.S.
Voltage Measurement:
Range: 0~80V
Readback Resolution: 1mV
Readback Accuracy (23±5°C): ≤0.03%+0.02%F.S.
Current Measurement:
Range: 0~60A
Readback Resolution: 1mA
Readback Accuracy (23±5°C): ≤0.1%+0.1%F.S.
Line Regulation:
Voltage: <0.02%F.S.
Current: <0.03%F.S.
Load Regulation:
Voltage: <0.03%F.S.
Current: <0.05%F.S.
Dynamic Characteristics:
Voltage Rise Time(no load): ≤10ms
Voltage Rise Time(full load): ≤10ms
Voltage Fall Time(no load): ≤20ms
Voltage Fall Time(full load): ≤10ms
Transient Recovery Time: The output voltage recovering within 0.75% of the rated output voltage value（10%~90% load)≤1ms
Others:
Isolation(Output to Ground): 500V DC
Max. Efficiency: 0.91
Power Factor: 0.99
Interface: LAN/RS232/RS485/CAN
Communication Response Time: ≤5ms
AC Input: 220V AC±10%,47Hz~63Hz,≤10A
Temperature: Operating temperature: 0°C~40°C, storage temperature: -20°C~70°C
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 5kg
Dimension: 44.5(H)*214.0(W)*556.2(D)mm, with output shield
