Stirring quantity max. per stirring position (H2O): 20 l
Motor rating input: 70 W
Motor rating output: 35 W
Motor principle: Brushless DC
Speed display: LED
Speed range: 60 - 2000 rpm
Intermittent operation: yes
Viscosity max.: 10000 mPas
Output max. at stirring shaft: 26 W
Permissible ON time: 100 %
Torque max. at stirring shaft: 150 Ncm
Torque max. at stirring shaft at 60 1/min (overload): 300 Ncm
Torque max. at stirring shaft at 100 1/min: 150 Ncm
Torque max. at stirring shaft at 1.000 1/min: 24 Ncm
Speed range I (50 Hz): 60 - 500 rpm
Speed range II (50 Hz): 240 - 2000 rpm
Speed range I (60 Hz): 72 - 600 rpm
Speed range II (60 Hz): 288 - 2400 rpm
Speed control: stepless
Setting accuracy speed: 1 ±rpm
Deviation of speed measurement: 30 ±rpm
Stirring element fastening: chuck
Chuck range diameter: 0.5 - 10 mm
Hollow shaft, inner diameter: 10.5 mm
Hollow shaft (push-through - when stopped): yes
Fastening on stand: extension arm
Extension arm diameter: 13 mm
Extension arm length: 160 mm
Speed control: mechanical
Nominal torque: 1.5 Nm
Dimensions (W x H x D): 88 x 294 x 212 mm
Weight: 3.1 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 20
Voltage: 220 - 240 / 100 - 115 V
Frequency: 50/60 Hz
Power input: 72 W
