Width: 62.5 mm
Height: 20.5 mm
Length: 152 mm
Fall Time: 77 ns
Rise Time: 261 ns
Technology: SiC
Configuration: Dual
Mounting Style: Press Fit
Number of Channels: 2 Channel
Vf - Forward Voltage: 4.14 V
Pd - Power Dissipation: 20 mW
Vgs - Gate-Source Voltage: - 10 V, + 23 V
Typical Turn-On Delay Time: 182 ns
Typical Turn-Off Delay Time: 319 ns
Id - Continuous Drain Current: 420 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 40 C
Rds On - Drain-Source Resistance: 1.91 mOhms
Vds - Drain-Source Breakdown Voltage: 1.2 kV
Vgs th - Gate-Source Threshold Voltage: 5.15 V
