SPECIFICATION
Resolution (adjustable) 0.01mm/m (2")
Range: +/-5mm/m
Repeatability: 0.01mm/m
Response time: <3s
Resolution (adjustable) 0.005mm/m (0.2")
Range: ±2.5mm/m
Repeatability: 0.005mm/m
Response time: <5s
Accuracy: ±(1+Ax2%)▲*
Power supply: 1 x 21700 Li-ion battery, for 50h continuous working
Weight: 1.8kg
*A is the measured value, ▲ is the resolution
STANDARD DELIVERY
Main unit: 1pc
Wireless receiver: 1pc
Control box: 1pc
Measuring software: 1 set
Charger: 1pc
■ Measures flatness, parallelism and straightness
■ Built-in bluetooth, can be connected to computers, transmission distance is 50m
■ The LCD can be rotated for easy observation in different directions
■ Designed with handle for easy access
■ V-groove on bottom for shafts
■ Supplied with measuring software
■ Optional accessory: bridge plate (code 4952-01)
