Applicable Brinell indenter: Φ10mm; Φ7.26mm Φ5mm; Φ4mm; Φ2.5mm
Hardness range: 16~650HB
Range of indentation diameter: Φ0.6~6mm
Test force: 62.5; 100; 125; 187.5; 250; 500; 750; 1000; 1500; 3000kgf
Hardness resolution: 1HB
Diameter measuring resolution: 0.001mm
Diameter measuring accuracy:
-±0.4% (indentation diameter)
-±0.8% (indentation diameter)
-±1.2% (indentation diameter)
Camera:
-Sensor: 1/3.2” CMOS
-Pixel: 2M (resolution 1600x1200)
-View filed: 8x6mm
Dimension: 170x54x54mm
Weight: 385kg
Standard delivery:
-Main unit: 1pc
-Software: 1pc
-5mm standard indentation block: 1pc
-10mm standard indentation block: 1pc
Optional accessory:
-2.5mm standard indentation block: ISHB-MSA-BLOCK25
