Magnification: 40X~600X
Eyepiece: 10X (view field: ϕ 20mm)
Infinite strain free plan achromatic objective: 4X(transmitted/reflected); 10X (transmitted/reflected); 20X (transmitted); 40X (transmitted); 60X (transmitted)
Working distance: 22.2mm; 6.1mm; 6.4mm; 0.6mm; 0.3mm
Numerical aperture: 0.1; 0.25; 0.4; 0.65; 0.8
Stage:
-Revolving round stage
-Diameter: ϕ160mm
-Graduation: 1 °
-Resolution: 6’
Pupil distance: 63~75mm
Diopter adjustment: ±5 diopter (one eyepiece)
Illumination:
-12V/50W halogen lamp, brightness is adjustable (reflected illumination)
-12V/50W halogen lamp, brightness is adjustable (transmitted illumination)
Power supply: 110/220V, 50/60Hz
Dimension: 614x250x394mm
Weight: 13kg
Standard delivery:
-Main unit: 1pc
-Micrometer: 1pc
-Grid plate: 1pc
-10X crossing eyepiece (view field: ϕ20mm)
-10X dividing eyepiece (view field: ϕ20mm, graduation: 0.1mm)
-λslip (first class red) and 1/4 λ slip
-Quartz wedge
Optional accessory:
-Objective for reflected system
-Objective for transmitted system
-Specimen presser
