Optical tube: binocular (20° inclined)
Eyepiece (wide field): 10X (view field: ϕ22mm)
Objective: 0.8X~8X (zoom)
Zoom ratio: 1:10
Pupil distance: 55~75mm
Diopter adjustment: ±5 diopter (both eyepiece)
Working distance of objective: 78mm
Max. workpiece height: 72mm
Illumination: adjustable reflected and transmitted LED light
Power supply: 110/220V, 50/60Hz
Dimension: 240x280x440mm
Weight: 4.3kg
Standard delivery:
-Main unit: 1pc
-WF 10X eyepiece: 2pcs
-Φ100mm glass plate: 1pc
-Φ100mm white/black plate: 1pc
-Anti-dust cover: 1pc
Optional accessory:
-Objective: 0.5X achromatic objective; 2X plan achromatic objective; 0.5X plan apochromatic objective
-Eyepiece: WF15X; WF20X; WF30X
-Sleeve for objective
-Iris diaphragm
-Optical path splitter
-Coaxial illumination
-Digital camera
