Basic
Sensor: IMX183
Image Sensor: 1"CMOS
Shutter: Rolling
Resolution: 5472 × 3648
Frame Rate: 6 fps
Bit Depth: 10
Mono/Color: Color
Pixel Size: 2.4 μm × 2.4 μm
Pixel: 20.0 MP
S/N Ratio: 38 dB
WDR: 60 dB
Image Format: Mono8,BayerRG8/10/10Packed,YUV422_8_UYVY,YUV422_8
Binning: Support
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1～32
White Balance: Support
Gamma: From 0 to 4, support LUT
Exposure Time: 16 μs～1 s
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 256MB
Port
Port: GigE, PoE
GPIO Interface: 1× 6 pin Hirose: 1× Opto-isolated input, 1× Opto-isolated output, 1 configurable input and output
Lens Mount: C-mount
Power
Power Supply: PoE/ DC 9V~24V power supply via Hirose interface
Power Consumption: 12 V≈3.6 W
Structure
Product Dimensions: 29 mm × 29 mm × 42 mm (not including lens mount and rear case connector)
Net Weight: 88 g
Environment
Storage Temperature: - 30℃～+80℃
Operating Temperature: 0℃～+50℃
