Width: 5.13 mm
Height: 26.16 mm
Length: 19.96 mm
Fall Time: 23 ns
Rise Time: 31 ns
Technology: Si
Unit Weight: 10 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 265 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 960 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 32 ns
Typical Turn-Off Delay Time: 87 ns
Id - Continuous Drain Current: 120 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 70 S
Rds On - Drain-Source Resistance: 24 mOhms
Vds - Drain-Source Breakdown Voltage: 300 V
Vgs th - Gate-Source Threshold Voltage: 5 V
