Working Stage:
Metal Stage Size: 458x358
Glass Stage Size: 250x350
X, Y, Z axis: 300x200
Drive System: X and Y Axes: Guide rod transmission; Z Axis: Ball screw transmission
Dimensions (L X w X H) (mm): 930x670x1100
Data Measurement System:
Optical scale resolution (x. Y. Z axes): 0. 0005 mm
X, Y coordinate indication error: < (3 + L/200) µm
Z-axis travel: 250 mm
Multi-function data processor supports measurement of points, lines, circles, arcs, center distances, angles, and workpiece alignment.
Imaging System:
High-resolution color CCD camera
Zoom lens: 0. 7 - 4. 5X
Total video magnification: 30 - 230X
With a 2X auxiliary lens, magnification can reach up to 440X
Illumination:
Lighting can be adjusted in four independent zones
Support Table Recommendations:
Load capacity: ≥ 450 kg
Dimensions (L X w X H): 1120 X 730 X 780 mm
