230V 50/60Hz.
Input fuse: T1A.
Earthing Fuse: F 1.25A.
Output: 23.5V
Peak power: 150 W - 23.5 V
Selectable temperature: 90 to 450 ºC / 190 to 840 ºF
Tip-to-ground resistance: <2 ohms
Tip-to-ground voltage: <2 mV RMS
Solder wire diameter: 0.4 - 1.6 mm / 0.02 - 0.06 in
Max. wire length: 250 mm / 9.84 in
Max. forward speed: 50 mm/s / 1.97 in/s
Speed of Backward Function: 0.0 to 5.0 mm/s / 0.5 to 0.20 in/s
Compatible Solder Reel
Weight: up to 2 kg
Diameter: max. 100 mm
Height: max. 100 mm
Weight and dimensions
Control Unit
235 x 170 x 112 mm / 5.81 kg.
9.25 x 6.69 x 4.41 in / 12.80 lb.
PRODUCT COMPOSITION
1 Instruction Manual
1 ALE Automatic-Feed Control Unit (guide components assembled)
1 GALE10V Guide Kit Ø 1.0 mm for ALE250 with perforation
