JTSE CONTROL UNIT
Peak power: 700 W
Selectable temperature: 150 to 450 °C / 300 to 840 °F
Air flow regulation: 5 to 50 SLPM
Vacuum: 30% / 228 mmHg / 9 inHg
Profiles: 25 (up to 10 steps for each), 1 preset profile
Type K TC connector: 1 for Control & Protection
ESD safe: Meet ANSI / ESD S20.20-2021
USB-A:
Firmware update
Graphics and profiles
USB-B: PC communications
RJ12 Connector: Remote control or FAE Fume Extractor connection
DDE CONTROL UNIT
Peak power: 150 W per tool
Selectable temperature: 90 to 450 ºC / 190 to 840 ºF
Temperature accuracy: ±3%
ESD safe: Meet ANSI/ESD S20.20-2021
Tip-to-ground resistance: <2 ohms
Tip-to-ground voltage: <2 mV RMS
USB-A:
Firmware update
Graphics and profiles
USB-B: PC communications
FAE / Robot connector: Remote control or FAE Fume Extractor connection
MSE MODULE
Vacuum: 75% / 570mmHg / 22.4inHg
Flow rate: 9 SLPM
ESD safe: Meet ANSI/ESD S20.20-2021
WEIGHT AND DIMENSIONS
Control Unit: 232 x 148 x 295 mm / 14.55 kg. (9.13 x 5.83 x 11.61 in / 32.09 lb.)
Package:700 x 410 x 390 mm / 20.20 kg. (27.56 x 16.14 x 15.35 in / 44.53 lb.)
