Sensitivity 5.1mV/(m/s2) (500mV/G) ±10%
Frequency range (±3dB) 0.2 to 10,000Hz *
Maximum measuring acceleration 98m/s2 (10G)
Shock survivability 9,800m/s2 (1,000G) Peak
Mounted resonance frequency 20kHz min.
Operating temperature range -20 to +80°C
Preserve temperature range -24.5 to +85°C
Weight 40g
Case material SUS303
Cable φ3 Coaxial cable (polyethylene-coated)
Mounting JIS M6, Length 6mm
Amplifier Preamplifier built-in
Excitation voltage +23 to +25VDC
Constant current excitation +3.9 to +5.1mA
Output bias voltage +14 to +16VDC
Electrical isolation Case isolated
Protection against ingress of water IPX7
