Technical parameters:
Microhardness scale: HV0.01,HV0.025,HV0.05,HV0.1,HV0.2,HV0.3,HV0.5,HV1
Display: 7 inch LCD touch screen
Test force (gf): 10，25，50，100，200，300，500，1000
Load control: Automatic (load/hold/unload)
Test force retention time (s): 5～60
Test force selection: External force selection knob, test force is automatically displayed on the 7-inch LCD touch screen
Objective lens magnification: 10×，40×
Optical channel: Dual optical channel (eyepiece and CCD camera channel)
Optical system (dual optical channels, no need to switch)）:
1. Automatic digital encoder;
2. Total magnification (μm): 100× (observation), 400× (measurement);
3. Measuring range (μm): 200; 4. Resolution (μm): 0.01
Hardness measurement range: (5-3000)HV
Maximum height of specimen (mm): 110
Maximum width of test piece (mm): 120（Distance from center line of indenter to machine wall）
voltage: AC220V/50HZ
Weight (kg): 40
