Technical Parameters:
Number of grinding discs: 2
Grinding disc diameter: 254mm
Grinding disc speed: Stepless speed regulation 100-1000r/min; Four-speed speed regulation 300 500 800 1000r/min
Grinding disc rotation direction: Bidirectional forward and reverse
Grinding head rotation direction: Clockwise
Grinding head speed: 0—120r/min
Grinding head motor: Stepper motor 200W
Grinding head locking method: Automatic lock
Timing adjustable time: 0-99min
Pressure method: Single point pneumatic pressurization
Pressure pressure: 0-0.5Mpa (commonly used 0.2-0.3Mpa)
Number of sample clamps: 4个
Clamped sample thickness: 8-22mm (customizable)
Sample clamping specifications: Standard Ф30, (any specification of Ф22 Ф30 Ф45 is optional, special specifications can be customized)
Power supply: 220V 50Hz
Dimensions: 755*660*710mm
Weight: 100kg
Main functions and features：
1. Super cost-effective, stable quality, complete functions, can be customized DIY according to different customer requirements.
2. The shell is made of ABS plastic, with novel appearance and corrosion resistance
3. The faucet adopts all-copper chrome plating process, which has good corrosion resistance
4. Touch screen control and display are adopted, which is easy to operate, clear and intuitive
5. It has the function of timing, speed and pressure
6. The grinding head adopts electromagnetic clutch automatic locking, which is convenient and fast
7. Supports stepless speed regulation or four-speed speed regulation mode, which is more convenient to regulate speed
8. Supports single-action and linkage start of grinding and polishing disc and grinding and polishing head, which is more flexible to use
9. It can store more than 10 sets of grinding and polishing process parameters, which is convenient for quick call
10. Magnetic disk design supports quick disk change, making it easier and quicker to change sandpaper and polishing fabric
11. The sample clamping disk automatically relaxes and tightens, and cooperates with the inner lighting system to facilitate the sample placement
12. Equipped with a fast sample clamping disk, the clamping disks of different diameters can be replaced at any time
13. The whole machine adopts a three-phase silent motor and a stepper motor, which rotates smoothly, has low noise and long service life
14. The emergency stop button can stop the operation immediately and quickly, which is safer
15. The double-disc design makes sample preparation more efficient
