Technical parameter：
Cutting method: Manual, Y-axis feed
Y-axis travel: 125mm
Cutting disc size: Φ250×2×Φ32mm
Maximum cutting section: 60X60mm
Cutting table size: 300X240mm
Spindle speed: 2800r/min
Motor power: 2.2kw
Machine power: 2.8kw
Cutting fixture: Threaded clamp
Lighting: Waterproof LED lighting
Water tank: Automatic circulation water tank
Input power: 380V, 50Hz, three-phase four-wire
Overall dimensions: 650x700x480mm
Weight: 100kg
Main functions and features
1. The main parts such as the shaft sleeve and the work surface are made of corrosion-resistant materials and have a long service life.
2. The workbench and the motor fixing frame are fixed and stable, and the surface is sandblasted, which is beautiful and durable
3. The workpiece is fixed with a quick clamp, which is convenient, fast, safe and reliable (optional)
4. The overall mechanism rotates smoothly, with low noise and long service life
5. The perspective adopts impact-resistant transparent PC board, which is safe and reliable
6. Waterproof LED lights are used for lighting, which is convenient for observing the entire cutting process
7. With cooling device and water tank, the coolant can be recycled, which is economical and efficient 8. The maximum cutting diameter is 60mm
