Capacity of work tank: 2300x1700x800mm
Work table size: 1580x1100mm
Longitudinal travel(X-axis): 1500mm
Cross travel(Y-axis): 1000mm
Z axis travel(Z-axis): 600mm
Distance between platen to table: 650~1250mm
Max. Electrode weight: 500kgs
Max. Work piece weight: 11000kgs
Fluid tank capacity: 3500L
Machine outside dimensions(WxDxH): 4600x4800x3620mm
Machine weight: 14500kgs
Max. Machining current: 90A; 120A(Optional)
Max. Power input: 10KVA; 13KVA
Max. Machining rate: 600; 800 mm3/min
Min. Electrode wear ratio: 0.12%
Best surface / Ra: Ra 0.2μm
Min. D. R. O. resolution(mm): 0.001mm
Generator weight: 350 kgs
