JSEDM MVC-1160G MVC Vertical Machine Center (6000 rpm)

X axis travel: 1100 mm

Y axis travel: 600 mm

Z axis travel: 610 mm

Spindle nose to table surface: 650 mm

Spindle center nose to column: 150 - 760 mm

Table work area: 1200 x 600 mm

Dimension of T-slot: CD 100 x 18 x 5T

Max. table load: 800 kg

Spindle taper / Bore diameter: BT50

Driving method: Gear Head

Spindle motor-cont / 30 min: 20 HP (Mitsubishi or Fanuc)

Spindle speed: 6000 rpm

Rapid feed rate - X / Y / Z: 20 x 20 x 18 m/min

X / Y / Z ball screw: 40 x 12B2 (dia. x pitch)

Max. tool length: 350 x 114.8 mm

Max. tool weight: 15 kg / 33 lbs

Number of tools: 24 pcs

Tool exchanging time: Bi-direction & Min Path

Gear ratio: 1:4.2

Bearings front: NN3018 (Ø90)

Bearings rear: NN3012 (Ø60)

Bearings lubrication: Grease

Preload: Rigid

Clamping force: 2000 kg

Coolant: Oil

Coolant requirement: 1500 keal/h

Min / Max. air pressure: 4 kg / 6cm²

Coolant tank capacity: 380 L

Net weight: 8500 kg

Gross weight: 8900 kg

Floor space requirement (L x W x H): 300 x 219 x 246 cm

Packing size (L x W x H): 310 x 228 x 250 cm

Container: 40"HQ
