JSEDM MVC-1370G MVC Vertical Machine Center (6000 rpm)

X axis travel: 1300 mm

Y axis travel: 700 mm

Z axis travel: 700 mm

Spindle nose to table surface: 760 mm

Spindle center nose to column: 150 - 850 mm

Table work area: 1400 x 700 mm

Dimension of T-slot: CD 125 x 18 x 5T

Max. table load: 1200 kg

Spindle taper / Bore diameter: BT50

Driving method: Gear Head

Spindle motor-cont / 30 min: 20 HP (Mitsubishi or Fanuc)

Spindle speed: 6000 rpm

Rapid feed rate - X / Y / Z: 20 x 20 x 18 m/min

X / Y / Z ball screw: 50 x 12B2 (dia. x pitch)

Max. tool length: 350 x 114.8 mm

Max. tool weight: 15 kg / 33 lbs

Number of tools: 24 pcs

Tool exchanging time: Bi-direction & Min Path

Gear ratio: 1:4.2

Bearings front: NN3018 (Ø90)

Bearings rear: NN3012 (Ø60)

Bearings lubrication: Grease

Preload: Rigid

Clamping force: 2000 kg

Coolant: Oil

Coolant requirement: 1500 keal/h

Min / Max. air pressure: 4 kg / 6cm²

Coolant tank capacity: 450 L

Net weight: 11000 kg

Gross weight: 12000 kg

Floor space requirement (L x W x H): 340 x 248 x 280 cm

Packing size (L x W x H): 700 x 228 x 250 cm / 385 x 310 x 315 cm

Container: 40"HQ splt into 2 pallets / 20" FR
