JST Commercial B4P-VH-FB-B-E(LF)(SN) Crimp Style VG SHROUDED HEADER
Manufacturer: JST Commercial Model: B4P-VH-FB-B-E(LF)(SN) - Contact
Pitch: 3.96 mm (0.156 in)
Wire Gauge: 22 AWG to 16 AWG
Housing Color: Natural
Contact Gender: Pin (Male)
Current Rating: 10 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 1 Row
Voltage Rating: 250 VAC/DC
Contact Plating: Tin
Contact Material: Copper
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: Crimp
Flammability Rating: UL94V-0
Number of Positions: 4 Position
Insulation Resistance: 1 GOhms
Termination Post Length: 3.7 mm (0.146 in)
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 25 C
