Performance Data Temperature
Temperature range (max. 24 °C below ambient temperature) [°C]: 0…70
Temperature variation at 40 °C [± K]: 0.5
Temperature fluctuation [± K]: 0.1
Performance Data Climate
Temperature range (max. 24 °C below ambient temperature) [°C]: 5…70
Temperature variation at 40 °C and 75 % RH [± K]: 0.5
Temperature fluctuation at 40 °C and 75 % RH [± K]: 0.1
Humidity range [% RH]: 10…80
Humidity fluctuation at 40 °C and 75 % RH [± % r.H.]: 0.4
Electrical data
Rated Voltage [V]: 200…230
Power frequency [Hz]: 50/60
Nominal power [kW]: 1.2
Unit fuse [A]: 16
Phase (Nominal voltage) [ph]: 1~
Outer dimensions without attachments and connections
Width net [mm]: 1254
Height net [mm]: 1925
Depth net [mm]: 1146
Wall clearance back [mm]: 100
Wall clearance sidewise [mm]: 180
Doors
Unit doors: 2
Internal Dimensions
Width [mm]: 973
Height [mm]: 1250
Depth [mm]: 836
Further Dimension
Interior volume [L]: 1020
Net weight of the unit (empty) [kg]: 322
permitted load [kg]: 150
Load per rack [kg]: 45
Environment-specific data
Energy consumption at 40 °C and 75 % RH [Wh/h]: 135
Sound-pressure level [dB(A)]: 49
Fixtures
Number of shelves (std./max.): 2/15
