Keithley 2268-80-10 Power Supplies (0-80V, 10.5A, 850W)

Name: Keithley 2268-80-10 Power Supplies (0-80V, 10.5A, 850W)
Brand: KEITHLEY

ManufacturerKEITHLEY

Model2268-80-10

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Manufaturer: Keithley - USA
Model: 2268-80-10
Output Voltage: 0-80 V
Maximum Output Current: 10.5 A
Maximum Output Power: 850 W
Line Regulation Voltage: 6 mV
Line Regulation Current: 2.1 mA
Load Regulation Voltage: 6 mV
Load Regulation Current: 6.1 mA
Output Noise Voltage (RMS, 300kHz) : 8 mV
Output Noise Current (RMS, 300kHz) : 25 mA
Output Ripple (peak‑peak, 20MHz) : 80 mV
Accuracy Voltage Programming: ±80 mV
Accuracy Current Programming: ±21 mA
Accuracy Power Programming: ±2.52 W
Accuracy Voltage Readback: ±80 mV
Accuracy Current Readback: ±21 mA
Accuracy Power Readback: ±2.52 W
Accuracy Meter Accuracy: 0.5% of output voltage or current ±1 count
DIGITAL INTERFACES: RS‑232,RS‑485,LAN, USB,GPIB
INPUT: 85VAC to 265VAC
DIMENSIONS: 44 mm × 214 mm × 495 mm
WEIGHT: 5 kg

Datasheet

The six models in the 850W DC power supplies in the Series 2268 provide voltage and current output levels well suited for automated test applications. They offer maximum voltage outputs of 20V, 40V, 60V, 80V, 100V, and 150V with corresponding maximum current outputs of 42A, 21A, 14A, 10.5A, 8.5A, and 5.6A. Series 2268 power supplies allow outputting any current, including the maximum current, at any voltage. They provide both analog and digital control options and a number of digital interface options and can operate in constant voltage (CV), constant current (CC), or constant power modes to address a broad array of applications. These high-efficiency, soft-starting power supplies provide reliable performance and long life.

Six 850W models with maximum voltage outputs from 20V to 150V, maximum current outputs from 42A to 5.6A
Compact 1U, half-rack enclosure provides the highest power in the smallest package
Two auxiliary outputs support driving or signaling external devices, often eliminating the need for additional instrumentation
Isolated analog inputs minimize control line noise
Built-in LAN, USB, GPIB, RS-232, RS-485 interfaces and analog inputs are all standard
Constant voltage, constant current, and constant power setting control
Auto sequence control supports internal execution of commands to minimize bus communication time
Control up to 30 supplies through a single controller interface
Foldback mode with programmable delay shuts down the output on transitions between CV and CC operation to protect voltage- or current-sensitive devices
Numerous safety features protect the load and the supply, including over-voltage and under-voltage protection, over-current protection, over-temperature protection, loop protection for multiple-supply configurations, and a hardware output interlock
