Maximum Output Power And Source Limits
50 W maximum per channel
± (50 V at 1 A)
± (10 V at 5 A)
Voltage Limit: 50.1 V
Load Effect (Regulation)
Voltage: ± (0.01% + 4 mV)
Current: ± (0.01% + 2 mA)
Ripple and Noise (Typical): (20 Hz to 20 MHz, 23°C ± 5°C)15
Voltage (Vp-p): ≤ 20 mVp-p
Voltage (VRMS): ≤ 5 mVRMS
Current (IRMS) (CC Mode): 4 mARMS
Supplemental Characteristics
Programming Ranges
Voltage: 0 V to ± 50.1 V
Current: 10 mA to 5.1 A
Programming Temperature Coefficient per Deg C
Voltage: ± (0.005% + 0.2 mV)
Current: ± (0.005% + 0.1 mA)
Measurement Temperature Coefficient per Deg C
Voltage: ± (0.01% + 0.2 mV)
Current: ± (0.01% + 0.1 mA)
Additional Offset at Faster Measurement Settings
Fast (Volt): 10 mV
Fast (Current): 50 mA
Common Mode Current Noise (20 Hz to 20 MHz)
RMS: < 1 mA
peak-to-peak: < 10 mA
Overvoltage Protection (OVP)
Setting Accuracy: ± (0.25% + 400 mV) at ≤ 1 A
Setting: 100 mV to 55 V
Response Time: 17 < 50 µs18
Overcurrent Protection (OCP)
Setting Accuracy: ± (1%+ 20mA)
Setting: 250 mA to 5.5 A
Response Time: 17 < 50 µs
Overtemperature Protection (OTP): Internally sensed temperature overload puts unit in standby mode
Programmable Slew Rate with a full resistive load (10% to 90%)19
Rising V / Falling V: Max 10kV / sec
Rising V / Falling V: Min 1V/ sec
General Specifications
Rear-Panel Connector:
Output: 8-pin terminal block socket
Output and Remote Sense Removable 8-8 pin screw-terminal block carries the following signals:
• Output Channels
• Max voltage drop across source leads: 1 V per lead
• Max source lead resistance: 0.5 Ohm
• Max sense leads resistance: 2 Ohms
• The load lead drop reduces the maximum available voltage at the load
• Remote Sense Lines: Connections for remote sense for each channel
EMC: Conforms to European Union EMC Directive
Safety:
NRTL listed to UL61010-1
Conforms to European Union Low Voltage Directive
Environment:
Conforms to European Union RoHS Directive
For indoor use only
Altitude: Maximum 6562 ft (2000 m) above sea level
Operating: 0 °C to 50 °C, 70 % relative humidity up to 35 °C. Derate 3 % relative humidity/°C, 35 °C to 50 °C
Storage: -25 °C to 65 °C
Dimensions 1.56 in (39.6 mm) height × 4.42 in (112 mm) width × 12.3 in (312 mm) length
Weight 2 lbs. (0.9 kg)
