KELI PSTA-5T Weight sensor (5000 kg)

Model: PST

Load capacity : 5T

Recommended input voltage ( excitation, recomended ) : 10~12 V

Maximum input voltage ( excitation, max): 15 V

Accuracy class : 0.03

Resolution ( rated output ) : 400∓20(200~300kg, 1.2~10t) Ω

Non-linearity: 0.03 %FS

Hysteresis error: ∓0.03 %FS

Combined error: ∓0.03 %FS

Non-repeatability: ∓0.02 %FS

 Latency (Creep error 30minutes): ±0.03% F.S

Input resistance : 400∓20(200~300kg, 1.2~10t) Ω

Output resistance : 352∓3 Ω

Insulation resistance : 5000 Ω

Operating temperature ( temperature, operating ): -30~+70 oC

Cable length: 2.6m(20~1000kg), 3m(1.2~10t) m

Protection class: IP65

Material made: Aluminum

Safe overload: 120 %FS

Ultimate overload: 200 %FS

Zero Balance: ∓1 %FS

TCO: 0.02 %F.S/10oC

TC SPAN: 0.02 %F.S/10oC
