- Range frequency: 20 Hz ~ 120 MHz
- Resolutionz: 1mHZ
- Measurement parameters: |Z|, |Y|, θ, R, X, G, B, L, C, D, Q, Complex Z, Complex Y, Vac, Iac, Vdc, Idc
- Level monitor : Vac, Iac, Vdc, Idc
- Built-in DC bias range: 0 V to ±40 V, 0 A to ±100 mA
- 4-channel & 4-trace on 10.4 inch color LCD with touch screen
- Data analysis function: Equivalent circuit analysis, limit line test
- Accuracy : ±0.08% (typical ±0.045%) basic impedance measurement accuracy
- Voltage Signal Level :
+ Range : 5 mVrms to 1 Vrms
+ Resolution : 1 mV
- Current Signal Level
+ Range : 200 µArms to 20 mArms
+ Resolution : 20 µA
- Output Impedance : 25 Ω (nominal)
- Frequency : 47 to 63 Hz
Voltage : 90-264 VAC (Vpeak > 120 V)
Power consumption : 160 W (Typical)
Weight : 14 kg
