- Output
Output voltage/current: ±60 V ±25 A
Peak current ±50 A (20 ms)
Output mode: CV
Frequency response: DC ~ 100 kHz: ±60V at no load, –3dB
Small-amplitude frequency response (reference value): DC ~ 300 kHz: ±10V at no load, –3dB
Internal resistance: 10mW or less
Power/load variation: 0.05% + 40 mV
Ripple noise: 40mVrms/100mVpp or less (at no load, factory-set default)
Rise/fall time: 1 µs or less (square wave 60 V)
- Signal source (internal signal source)
Built-in waveform (fixed): ISO 7637 TEST PULSE 2b, TEST PULSE 4
Built-in waveform (arbitrary): Line, sine waveform, square waveform, sine sweep, square sweep, etc
- Signal source (external signal input)
Frequency range: DC ~ 300 kHz
Gain: Up to 60 V of gain can be controlled with × 6 (±10 V), × 12 (±6 V)voltage.
Input impedance: 10 kW or less
- Others
I/F: RS232C
Power consumption: 4 kVA or less
Operating temperature range: +5˚C ~ +35˚C
Operating humidity range: 30% ~ 85%rh (dew condensation not allowed)
Storage temperature range: 0˚C ~ +40˚C
Storage humidity range: 30% ~ 85%rh (dew condensation not allowed)
Dimensions: 440(17.32”)W×1010(39.76”)H×610(24.01”)D mm
Weight: Approx. 120 kg(264.55lbs)
