Voltage: 5 up to 270 VAC / 300 VDC
Rated current: max. 40 A
Starting current (short-term): up to 100 A
Frequency: DC, 50 Hz, 60 Hz
Power: 2000 VA @ 230 V, 1700 VA @ 110 V
Measurement voltage: 0 up to 300 VAC/DC
Measurement current: 0 up to 100 AAC/DC
Power supply: Rated voltage 100...240 VAC, 47...63 Hz, current max. 20 A
Connections: Industrial plug connectors
Housing: 19", 4 U
Dimensions (W × H × D): 450 × 177 × 460 mm
Screen: High-resolution, resistive 3.5" touchscreen
Weight: 19.7 kg
Operation: Jog wheel and 6 function keys
Display elements: 6 status LEDs, status signals on screen, illuminated ring on jog wheel
Interfaces: RJ45 (Ethernet), USB-B
