Volume: 1000L
Inner size: W 1500 mm*H 750 mm*D 800 mm
Exterior size: W 1700 mm*H 1785 mm*D 1900 mm (Not include machine protruding parts!)
Area: About 3.23m2；(Confirm after signing the contract)
Technical parameters
Test Conditions: Equipment cooling method: air-cooled
Measured at room temperature: + 25 ℃ with no load
Temperature range: -20℃ ～ +100℃
Temperature fluctuation: ±0.5℃
Temperature uniformity: ≤2.0℃
Temperature deviation: ≤±2.0℃
Temperature change rate:
Heating rate: -20℃～+100℃， Average 3℃/min；（no load）
Cooling rate: +100℃～-20℃， Average 1℃/min；（no load）
Maximum load: 50Kg LCD Panel, 250W heat compensation
Humidity range: 50～95%R.H
Temperature and humidity range: Humidity deviation, ±3.0％RH（＞75％RH）±5.0％RH（≤75％RH）
Humidity uniformity: ±3.0％RH（no load）
Humidity fluctuation: ±2.0％RH
Noise: ≤75(dB) （The noise detection device is measured 1m away from the equipment door）
Power source specification: 380V AC(±10%)
Three-phase line + protection ground, grounding resistance ≤ 4Ω .
Power frequency: 50±0.5Hz
Ground protection: Ground resistance ≦4Ω .
Drain connection: Pagoda connector plug φ10 inner diameter silicone hose
Note: Guide the condensed water out of the cabinet.
Power supply wiring:
1. Standard power cord: 3m
2. Customers should provide a dedicated fusion-free switch for the equipment.
