Optical Head: Inclined optical head, Symmetrical eye distance adjustment (55 – 75 mm), Dioptre compensation with scale
Objective Revolver: 3-times
Objectives: Planachromatic:
4x/NA 0.10 // object field Ø: 4.5 mm
10x/NA 0.25 // object field Ø: 1.8 mm
40x/NA 0.65 // object field Ø: 0.45 mm
Eyepieces: 10x plane eyepiece; Field of view: 18
Condenser: Double lens ABBE Condenser, NA 1.25, with centering and height adjustment
Illumination: 6 V 30 W adjustable
Magnification: 40 to 400
Microscope Stage: XY Stage, moving range 120x80x mm
Stand: 6 V 30 W adjustable objectives
Maximum Object Height:
24 mm with 4x/NA 0.10
23 mm with 10x/NA 0.25
21 mm with 40x/NA 0.65
Further Equipment: Iris diaphragm; Filter holder; Blue filter; Green filter (optional)
Power Supply: 90–240 V
