Conductor size: Ø68mm
Rated current: AC 100A
Output voltage: AC 5000mV/100A (AC 50mV/A)
Accuracy:
0 - 80A
±1.0%rdg±0.1mV (50/60Hz)
±2.0%rdg±0.2mV (40Hz - 1kHz)
80 - 100A
±5.0%rdg (50/60Hz)
±10.0%rdg (45Hz - 1kHz)
Cable length: Approx. 2m
Output connector: MINI DIN 6pin
Output impedance: Approx. 60Ω
Applicable standards: IEC 61010-1:2001,
IEC 61010-2-032:2002,
CAT III 300V pollution degree 2
Operating temperature & humidity range: 0 - 50ºC, less than 85% RH (without condensation)
Dimensions: 100(L) x 60(W) x 26(D) mm
Weight: Approx.150g
Included Accessories: 9095 (Portable case), Instruction manual, Cable marker
Optional Accessories: 7146 (Banana Ø4 adjuster plug), 7185 (Extension Cable)
