Capacity: 22 L
Sterilization Temperature: 121°C, 134°C
Sterilization Time: 4 min – 60 min
Times of Sterilization after filled up: 3-4 times
Working Pressure: 0.21 – 0.23 MPa
Pressure Sensor: Yes
Precision of Pressure Sensor: 0.1 KPA
Precision of Temperature Sensor: 0.1°C
Water supply system: Manual
Water Tank: 2 x 1.5 L Internal Stainless Steel water tanks
Type of vacuum pump: Double head
Vapour Filter: Yes
Temperature Sensor: Yes
Automatic protection when overpressure: Yes
Automatic protection when overtemperature: Yes
Lock system of door: Mechanic + Electrical lockers
Screen size: 2.5 x 2 cm, 3.8x 2 cm
Life span: 5 years
Hot air exhaust system: Copper condenser, fan
121°C Solid: Yes
121°C Porous: Yes
121°C Hollow: Yes
134°C Solid: Yes
134°C Porous: Yes
134°C Hollow: Yes
B&D Test: Yes
Helix Test: No
Vacuum Test: Yes
Clean Program: No
Prion Program: No
User Define: No
Chamber Dimension: 250×450 mm
Diameter of chamber: 250 mm
Depth of chamber: 450 mm
Inner Dimension: 700 X 445 X 390 mm
Overall Dimension (LxWxH): 700x445x390 mm
Packing Size: 790 X 500 X 495 mm
Minimum size of table for installation: 480 X 320 mm
Chamber Material: Stainless Steel SUS 304
Plug: 3 hole plug
Tray: 3
Sterilization programs: Yes/No
Weight: 43/52 kg
Wattage: 1700 W
Power: 1700 W
Power Supply: 220 V, 60 Hz
Optional Accessories:
Accessory Code Name Unit
AX1022 Ring 1
AX1023 Inner temperature sensor 1
AX1024 pt1000 1
AX1025 pt1000 (packing with plastic) 1
AX1026 Heating circle 1
AX1027 Steam generator cover 1Set
AX1028 Steam generator stand 1Set
AX1029 Steam generator spring type gasket 1
AX1030 Heating Rod 3
AX1031 Water Pump 1
AX1032 Vacuum Pump 1
AX1033 Fuse Wire 2
AX1034 Normally closed solenoid valve 3
AX1035 Three-way solenoid valve 2
AX1036 Germ-tight filter 1
AX1037 Voltage transformer 1
AX1038 switch 1
AX1039 Bleeder valve 2
AX1040 Fan 1
AX1041 Printer 1
AX1042 Control panel 1set
AX1043 LED 1set
AX1044 Big Pipe 1Kg
AX1045 Small Pipe 1kg
AX1046 Liquid sensor 3
AX1047 Electromagnet 1
