TABLE DIMENSIONS
Side to Side: 11.8 in. (30 cm)
Front to Back : 11.8 in. (30 cm)
TEST CAPABILITIES
Max. Acceleration: 5000g (10000g optional)
Min. Pulse Duration: 0.25 msec (half sine)
Max. Velocity Change : 22 – 55 ft./sec (6.7 – 16.8 m/sec)
Pulse Waveforms : Half Sine; Trapezoidal*; Terminal Peak Sawtooth* (*with Optional Programmers )
MAXIMUM PAYLOAD: 110 lbs. (50 kg)
MACHINE ENVELOPE DIMENSIONS
Height: 98 – 146 in. (249 – 371 cm)
Side to Side: 21 in. (53 cm)
Front to Back: 24 in. (61 cm)
POWER REQUIREMENTS
Machine : 200 – 240 VAC/3Φ/50 – 60 Hz: 8 amp min.; 380 – 480 VAC/3Φ/50 – 60 Hz: 4 amp min.
Controller: 100 – 120 VAC/1Φ/50 – 60 Hz: 3 amp min.; 200 – 240 VAC/1Φ/50 – 60 Hz: 3 amp min.
PNEUMATIC REQUIREMENTS
Plant Air: 90 psi (6.2 bar)
