Technical Specifications
Test Signal: 0.65, 0.1, +/-5% Vrms Sine Wave
Test frequency: 1 kHz, 10 kHz, 120 Hz, 100 Hz
Test Frequency Accuracy: 0.01%
Source Resistance: 1kΩ
Measurement Ranges
Resistance R: 5mΩ to 20 MΩ
CapacitanceC: 1 pF to 680 mF
Inductance L: 10 nH to 100 H
Quality factor Q: 0.001 to 1000
Dissipation factor D: 0.001 to 1000
Physical Specifications
Size: 180 x 30 x 16 mm (7.1 x 1.1 x 0.63 in.)
Weight: 45 grams (1.5 oz.)
Operating temperature: 10°C to 40°C
Battery Type: 3.7V LiPO rechargeable 250mAH
Battery Life (continuous): 80 hours, 2 hours charging cycle
