Measurement Technology: Quartz Crystal / electrochemical
Impurity Detected: H₂O / O₂
Sample Gas: Multiple Gases
Ranges (Default)*:
0–10ppm
0–100ppm
0–1000ppm
Up To 2000ppm Available (up to 25% available with O₂ electrochemical)
Limit Of Detection (LDL): 100ppb (with moisture trap and electric solenoid valve)
Accuracy: <+/- 1% Of Scale
Response Time (T90): <5 Min
Sensor Life Expectation: 3–5 Years
Operating Temperature Range: 5–45 Celsius
Sample Gas Temperature: 0–100 Celsius
Sample Flow Requirement: 100ml/Min Per Sensor Installed
Operating Sample Pressure Range: 5–30psig
Outlet Pressure:: Atmospheric
Inlet Fittings: 1/8" VCR
Outlet Fittings: 1/8" VCR
Standard Features: Modbus, Web Interface (Admin)
Supply: 24VDC (Power Supply Included For 85VAC/240VAC)
Weight: 10lbs (4.5kg)
Output: 4-20mA
EC: O2 electrochemical
