Gain: 3.8 dBi
VSWR: 1.9
Style: Ceramic
Width: 9.14 mm
Height: 10.16 mm
Length: 12.7 mm
Bandwidth: 150 MHz
Impedance: 50 Ohms
Technology: Monopole
Wavelength: 1/4 Wave
Application: Handheld Applications, Remote Controls, Pagers, Alert Devices, Portable Devices
Polarization: Linear
Mounting Style: PCB Mount
Electrical Type: Embedded Monopole
Number of Bands: 1 Band
Center Frequency: 2.45 GHz
Mechanical Style: Chip
Ground Plane Size: 19.56 mm x 38.74 mm
Maximum Frequency: 2.54 GHz
Minimum Frequency: 2.37 GHz
Termination Style: SMD/SMT
Protocol - Sub GHz: ISM
Protocol - WiFi - 802.11: WiFi
Maximum Operating Temperature: + 130 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
