Gender: Pin (Male)
Polarity: Standard
Impedance: 50 Ohms
RF Series: N Type
Body Style: Straight
Cable Type: RG-8, 8/U, Belden 9913, 9914, LMR-400
Orientation: Straight
Body Material: Brass
Mating Cycles: 500 Cycles
Insertion Loss: - 0.17 dB, - 0.46 dB
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 2.5 kV
Contact Plating: Gold
Contact Material: Brass
Maximum Frequency: 11 GHz
Termination Style: Crimp
Coupling Mechanism: Threaded
Contact Termination: Crimp
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 60 C
