Gender: Jack (Socket)
Polarity: Standard
Impedance: 50 Ohms
RF Series: N Type
Body Style: Flange
Cable Type: RG-55, 142/U, 223, 400
Orientation: Straight
Body Material: Brass
Mating Cycles: 500 Cycles
Insertion Loss: - 0.18 dB, - 0.35 dB
Mounting Style: Panel Mount
Voltage Rating: 2.5 kV
Contact Plating: Gold
Contact Material: Phosphor Bronze
Maximum Frequency: 11 GHz
Termination Style: Crimp
Coupling Mechanism: Threaded
Contact Termination: Crimp
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 60 C
