Gender: Pin (Male)
Polarity: Standard
Impedance: 50 Ohms
RF Series: SMA
Body Style: Edge Mount
Body Finish: Gold
Orientation: Straight
Unit Weight: 8.006 g
Body Material: Brass
Mating Cycles: 500 Cycles
Mounting Style: Edge Launch
Voltage Rating: 1 kV
Contact Plating: Gold
Contact Material: Brass
Maximum Frequency: 18 GHz
Minimum Frequency: DC
Termination Style: Solder
Coupling Mechanism: Threaded
Insulation Resistance: 5 GOhms
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
