• Combustion box internal dimensions: W300*H1200*D450mm
• Gas: High purity propane gas (Prepared by user)
• The tested wire/cable length: 600±25mm
• The outer diameter of the tested wire: the conductor diameter is greater than 0.8mm or the cross-sectional area is greater than 0.5mm2
• The flame should continuously burning the sample and the flame burning time T range is 0.1-999.9 (seconds) continuously
• Gas flow range: 0.1-1L/min; Air flow range: 3-30L/min; Box material: Iron plate spraying
• Standard power of combustion burner: 1kW
• User need to prepare air compressor
