Littelfuse 0448.800MR Surface Mount Fuses 125VAC 0.8A .1907ohms 448 NANO2
Manufacturer: Littelfuse Model: 0448.800MR - Contact
Width: 2.69 mm
Height: 2.69 mm
Length: 6.1 mm
Fuse Type: Fast Blow
Resistance: 190.7 mOhms
Unit Weight: 500.167 mg
Current Rating: 800 mA
Interrupt Rating: 50 A at 125 VAC, 50 A at 125 VDC
Fuse Size / Group: 6.1 mm x 2.69 mm
Voltage Rating AC: 125 VAC
Voltage Rating DC: 125 VDC
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
