Littelfuse S602TSRP SCRs Sen SCR 600V 1.5A 200uA
Manufacturer: Littelfuse Model: S602TSRP - Contact
Width: 3.5 mm
Height: 1.8 mm
Length: 6.5 mm
Unit Weight: 112 mg
Current Rating: 950 mA
Mounting Style: SMD/SMT
Vf - Forward Voltage: 1.7 V
Holding Current Ih Max: 5 mA
Breakover Current IBO Max: 15 A
Gate Trigger Current - Igt: 200 uA
Gate Trigger Voltage - Vgt: 800 mV
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
On-State RMS Current - It RMS: 1.5 A
Non Repetitive On-State Current: 15 A
Maximum Gate Peak Inverse Voltage: 5 V
Off-State Leakage Current @ VDRM IDRM: 5 uA
Rated Repetitive Off-State Voltage VDRM: 600 V
