Width: 44.9 mm
Height: 29.3 mm
Length: 57.6 mm
IP Rating: IP20
Input Current: 7 mA to 12 mA
Mounting Style: Panel Mount
Termination Style: Screw
Relay Contact Form: SPST-NO
Load Current Rating: 50 A
Load Voltage Rating: 48 VAC to 600 VAC
On Resistance - Max: 6.3 mOhms
Control Voltage Range: 4 VDC to 32 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 40 C
