Littelfuse TRF250-145U PolySwitch Resettable Fuses .145A 60VDC MAX 250Vrms MAX
Manufacturer: Littelfuse Model: TRF250-145U - Contact
Width: 6 mm
Height: 3.8 mm
Length: 10 mm
Resistance: 14 Ohms
Unit Weight: 190 mg
Hold Current: 145 mA
Lead Spacing: 5 mm
Trip Current: 290 mA
Mounting Style: PCB Mount
Maximum Voltage: 60 VDC
Termination Style: Radial
Current Rating - Max: 3 A
Pd - Power Dissipation: 1 W
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
