Extrude the material part
Discharging mouth diameter: Φ 2.095 ±0.005 mm
Length of discharge port: 8.000± 0.025 mm
Charging tube inner diameter: Φ 9.550 ± 0.025 mm
Length of charging barrel: 152± 0.1 mm
The piston rod head diameter: Φ 9.475± 0.015 mm
Piston rod head length: 6.350 0.100 mm
Effective stroke of piston rod: 30 mm
The range of temperature: room temperature to 400 ℃
The temperature control precision: plus or minus 0.2 ℃
Temperature fluctuations: plus or minus 0.2 ℃
The temperature resolution: 0.1 ℃
Temperature recovery time: 4min
Test method: quality method (MFR)
Measurement range: 0.1 ~ 300g / 10min(MFR)
Timing accuracy: 0.1s (MFR, MVR)
Cutting method: automatic (during the test), manual (when the instrument is adjusted)
Cutting times: 9 times
Cutting interval: 9999.9 seconds
Number of saved results: 20 copies
Printer configuration: panel thermal printer
Power supply: 220V, 50Hz
Power: 490W
Overall dimensions: 290 x 410 x 630 (mm)
