Lonroy BGD 520/B Automatic Scratch Test Machine (0.03±0.005 mm)
Manufacturer: Lonroy Model: BGD 520/B - Contact
Conform standards: ISO 1518-2
Cutting tip is diamond (diamond), and the tip is rounded to a radius of (0.03±0.005) mm
Angle between stylus and sample: 90°
Weight(Load): Variable-loading: 0g～50g or 0g～100g or 0g～200g
Motor: 60W 220V 50HZ
Sytlus Moving Speed: 10±2 mm/s
Working Distance: 120mm 100mm
Max Panel Size: 200mm×100mm
Max Panle Thickness: Less than 12mm
Overall Size: 500×260×340mm
Net Weight: 17.5KG
