Scope of application:
1, ferrous metal, non-ferrous metal, IC sheet, surface coating, laminated metal;
2, Glass, ceramic, agate, gemstone, thin plastic, etc.
3, Hardness test of the depth and gradient of carbonization layer and quenching layer;
4, suitable for horizontal plane and small parts and ultra-thin parts of precision Vickers measurement.
Technical specification
Measuring range: 5-5000hv
Test force: 0.3, 0.5, 1.0, 2.0, 2.5, 3.0, 5.0, 10, 20, 30, 50kgf
Loading mode: electric loading:
Data entry mode: automatic
Turret mode: manual
Specimen allow maximum height: 200mm
The center of the indenter is separated from the machine wall: 130mm
Lens magnification: 10×, 20×
Magnification: 100×, 200×
The minimum step: 0.1μm
Hardness resolution: 0.1hv
Power supply: ac 220v, 50hz
Overall dimensions: 620*330*650mm
Weight: 75kg
