Max testing force (kn): 300
Test force measurement range 1%-100%
Relative error of test force indication value: <±0.5%
Load display resolution: 1/500000 of the maximum test force
Distortion measuring range: 1%-100%
Relative error of deformation indication value: <±0.5%
Deformation resolution: maximum deformation 1/500000
Relative error of displacement indication value: < ±0.5%
Resolution of displacement (mm): 0.001
Range of speed: 0.01mm/min ~ 400mm/min /step less speed regulating
Stroke of stretch (mm): 600
Compression space (mm): 600
Width of test (mm): 550
Configurable fixture: Stretch, compress, bend, cut, peel, tear, etc
Dimension (mm): About 1060×810×2280mm
Servo motor power (kw): 3
Weight (kg): 1200
